Shaft Dia. |
Dimensions(mm) |
Bolt
Size |
Bearing
No. |
Housing No. |
Mass
(kg) |
|
Available |
|
d |
H |
L |
J |
A |
N |
N1 |
H1 |
H0 |
S |
B |
|
N |
N1 |
|
(in.) |
(mm) |
|
|
UCP202
202-10
203
203-11 |
5/8
11/16 |
15
17 |
30.2 |
125 |
96 |
32 |
12 |
16 |
13 |
57 |
11.5 |
27.4 |
M10 |
UC202
202-10
203
203-11 |
P203 |
0.6 |
|
-- |
-- |
|
UCP204-12
204 |
3/4
|
20 |
33.3 |
127 |
96 |
37 |
13 |
16 |
14 |
63.8 |
12.7 |
31 |
M10 |
UC204-12
204 |
P204 |
0.65 |
|
13 |
19 |
|
UCP205-14
205-15
205
205-16 |
7/8
15/16
1 |
25 |
36.5 |
140 |
105 |
38 |
13 |
19 |
15 |
69.5 |
14.3 |
34 |
M10 |
UC205-14
205-15
205
205-16 |
P205 |
0.72 |
|
-- |
-- |
|
UCP206-18
206
206-19
206-20 |
1-1/8
1-3/16
1-1/4 |
30 |
42.9 |
160 |
121 |
44 |
14 |
19 |
16 |
82 |
15.9 |
38.1 |
M12 |
UC206-18
206
206-19
206-20 |
P206 |
1.15 |
|
17 |
21 |
|
UCP207-20
207-21
207-22
207
207-23 |
1-1/4
1-5/16
1-3/8
1-7/16 |
35
|
47.6 |
167 |
126 |
48 |
15 |
19 |
17 |
92 |
17.5 |
42.9 |
M12 |
UC207-20
207-21
207-22
207
207-23 |
P207 |
1.53 |
|
17 |
21 |
|
UCP208-24
208-25
208 |
1-1/2
1-9/16
|
40 |
49.2 |
180 |
136 |
52 |
15 |
21 |
18 |
98 |
19 |
49.2 |
M12 |
UC208-24
208-25
208 |
P208 |
1.88 |
|
17 |
23 |
|
UCP209-26
209-27
209-28
209 |
1-5/8
1-11/16
1-3/4 |
45 |
54 |
189 |
146 |
54 |
15 |
21 |
20 |
105.5 |
19 |
49.2 |
M12 |
UC209-26
209-27
209-28
209 |
P209 |
2.1 |
|
17 |
23 |
|
UCP210-30
210-31
210 |
1-7/8
1-15/16 |
50 |
57.2 |
204 |
159 |
57 |
19 |
22 |
21 |
112.2 |
19 |
51.6 |
M16 |
UC210-30
210-31
210 |
P210 |
2.5 |
|
-- |
-- |
|
UCP211-32
211-34
211
211-35 |
2
2-1/8
2-3/16 |
55 |
63.5 |
217 |
172 |
604 |
19 |
22 |
22 |
124.5 |
22.2 |
55.6 |
M16 |
UC211-32
211-34
211
211-35 |
P211 |
3.3 |
|
-- |
-- |
|
UCP212-36
212
212-38
212-39 |
2-1/4
2-3/8
2-7/16 |
60
|
69.9 |
238 |
186 |
66 |
19 |
25 |
24 |
137 |
25.4 |
65.1 |
M16 |
UC212-36
212
212-38
212-39 |
P212 |
5.5 |
|
-- |
-- |
|
UCP213-40
213 |
2-1/2
|
65 |
76.2 |
262 |
203 |
70 |
23 |
29 |
26 |
149 |
25.4 |
65.1 |
M20 |
UC213-40
213 |
P213 |
5.6 |
|
25 |
29 |
|
UCP214-44
214 |
2-3/4
|
70 |
79.4 |
266 |
210 |
72 |
23 |
29 |
27 |
155 |
30.2 |
74.6 |
M20 |
UC214-44
214 |
P214 |
6.6 |
|
25 |
29 |
|
UCP215
215-48 |
3 |
75
|
82.6 |
274 |
217 |
74 |
25 |
29 |
28 |
161.6 |
33.3 |
77.8 |
M20 |
UC215
215-48 |
P215 |
7.3 |
|
-- |
-- |
|
UCP216 |
|
80 |
88.9 |
292 |
232 |
78 |
25 |
30 |
30 |
174 |
33.3 |
82.6 |
M20 |
UC216 |
P216 |
8.3 |
|
-- |
-- |
|
UCP217-52
217 |
3-1/4
|
85 |
95.2 |
310 |
247 |
83 |
25 |
30 |
32 |
186 |
34.1 |
85.7 |
M20 |
UC217-52
217 |
P217 |
10.8 |
|
-- |
-- |
|
UCP218-56
218 |
3-1/2
|
90 |
101.6 |
326 |
262 |
88 |
27 |
30 |
33 |
198 |
39.7 |
96 |
M22 |
UC218-56
218 |
P218 |
13 |
|
27 |
33 |
