Housing
NO. |
Bearing
NO |
BEARING BORE DIA.
d(mm) |
DIMENSIONS (MM) |
Bolt Dia. |
WEIGHT
(kg) |
|
|
a |
e |
b |
g |
l |
s |
z |
i |
Bi |
n |
|
TP-FL201 |
SUC201 |
12 |
113 |
90 |
65 |
11.4 |
26.5 |
11 |
33.7 |
15.4 |
31 |
12.7 |
M10 |
0.08 |
|
|
TP-FL202 |
SUC202 |
15 |
113 |
90 |
65 |
11.4 |
26.5 |
11 |
33.7 |
15.4 |
31 |
12.7 |
M10 |
0.08 |
|
|
TP-FL203 |
SUC203 |
17 |
113 |
90 |
65 |
11.4 |
26.5 |
11 |
33.7 |
15.4 |
31 |
12.7 |
M10 |
0.08 |
|
|
TP-FL204 |
SUC204 |
20 |
113 |
90 |
65 |
11.4 |
26.5 |
11 |
33.7 |
15.4 |
31 |
12.7 |
M10 |
0.08 |
|
|
TP-FL205 |
SUC205 |
25 |
131 |
99 |
69.5 |
13.5 |
29.1 |
11 |
36.7 |
17 |
34.1 |
14.3 |
M10 |
0.10 |
|
|
TP-FL206 |
SUC206 |
30 |
148 |
117 |
80 |
13.3 |
30.5 |
11 |
41.2 |
19 |
38.1 |
15.9 |
M10 |
0.13 |
|
|
TP-FL207 |
SUC207 |
35 |
164 |
130 |
90 |
16.1 |
32.8 |
13 |
43.4 |
18 |
42.9 |
17.5 |
M12 |
0.16 |
|
|
TP-FL208 |
SUC208 |
40 |
176 |
144 |
100 |
20 |
37.5 |
14 |
51.7 |
21.5 |
49.2 |
19 |
M12 |
0.24 |
|
|
TP-FL209 |
SUC209 |
45 |
188.5 |
148.5 |
106 |
21 |
41 |
17 |
54.2 |
24 |
49.2 |
19 |
M16 |
0.3 |
|
|
TP-FL210 |
SUC210 |
50 |
197 |
157 |
115 |
21 |
43 |
17 |
57.6 |
25 |
51.6 |
19 |
M16 |
0.33 |
|
|
